CWWK Mini PC 13th Intel i7-1355U(10C/12T,up to 5GHz), 6*Intel i226-V 2.5G Ethernet Ports 10-core Soft Routing,2*USB3.2|1*TF Slot|2*SATA|1*M.2 NVMe x4|Triple Display 4K,64G RAM 1TB SSD.
We independently review everything we recommend. When you buy through our links, we may earn a commission. As an Amazon Associate we earn from qualifying purchases. Product information — including images, features, availability, and prices — is based on data available at the time the content was published. Learn more ›
CWWK Mini PC 13th Intel i7-1355U(10C/12T,up to 5GHz), 6*Intel i226-V 2.5G Ethernet Ports 10-core Soft Routing,2*USB3.2|1*TF Slot|2*SATA|1*M.2 NVMe x4|Triple Display 4K,64G RAM 1TB SSD.
Be the first to rate this
Highlights
- Intel's new 13th generation RaptorLake platform low-power 7nm processor, large core + small core architecture high-performance processor, basic TDP power consumption is only 15W.
- Double copper tube turbine active fan heater allows the system to operate efficiently and stably, and the DC12-19V wide voltage power input allows the machine performance to be fully utilized.
- M.2 M Key PCIe3.0 x4 signal (supports 2280 specification hard drive), M.2 E Key supports WiFi6 module and supports NVMe hard drive through the adapter board,Onboard 2 12pin non-standard SATA3.0 hard drive sockets
- Dual-channel SO-DIMM DDR4 memory is compatible with 2666/3200 GHz Max 64G, HDMI+DP+Type display output supports three-screen 4K high-definition display, Reserved TF card socket for system booting or data storage making it easy to set up and use.
- If you have any questions on CWWK Firewall mini pc, feel free to contact us . We offered 12 Months warranty for it and WE'LL REPLY YOUR Quesstions within 24 hours(during Working Days).
Description
●Processor:i7-1355U ●Memory: 2*SO-DIMM DDR4 3200 (compatible with 2400/2666MHz) maximum 64G ●Hard drive: 1*M.2 NVMe x4 2*SATA (non-standard 12Pin 2.5-inch interface) ●Graphics card: 13th generation Intel Ultra Core Graphics/Iris XE graphics card ●Display: i7-1355U(96UE) HDMI 1.4 supports 3840x2160@60Hz DP 1.4 supports 7680x4320@60Hz Type-C supports 4090x2304@60Hz ●Network card: 6*Intel i226-V 2.5G network card ●WiFi: 1*M.2 E key (supports WiFi6/Bluetooth module) ●USB: 2*USB3.0, 2*USB3.2(10Gbps) ●Heat dissipation: Double copper tube turbine active heat dissipation (whole copper sheet on the surface) ●BIOS: AMI EFI BIOS with support for Auto power-on , GPIO, Wake On Lan ●Power consumption: 15W (basic power consumption), 55W (maximum turbo frequency power consumption) ●Power supply: DC12-19V wide voltage power supply (55*25 connector) ●Chassis: Aluminum alloy material ●Extension pins: 1*USB2.0 1*COM serial port 1*CPU_FAN(5V) 1*F_PANEL ●Dimensions: 145.4mm (length) X 131.7mm (width) X 60.0mm (height) ●Color: Gray/Black ●Installation method: Desktop type, (you can contact customer service to purchase additional wall hangings) ●Working environment: -0°C ~+70°C, relative humidity 5%-85% ●Suitable for computer enthusiasts DIY projects, light office use, software routing, virtualization, edge computing, small-scale NAS, and running industry-specific software applications
Photos
Product specs
| Specification | Details |
|---|---|
| Screen Resolution | 3840 x 2160 |
| Max Screen Resolution | 3840 x 2160 pixels |
| Processor | 5 GHz celeron |
| RAM | 64 GB DDR4 |
| Hard Drive | 1 TB SSD |
| Graphics Coprocessor | Intel Iris Xe Graphics |
| Chipset Brand | Intel |
| Card Description | Integrated |
| Number of USB 3.0 Ports | 4 |
| Brand | CWWK PC |
| Series | i7-6L-64G 1TB |
| Hardware Platform | PC, Linux |
| Operating System | OPNsense/OpenWrt/OpenVPN/Unbutun/windows /ESXI/Linux vmware etc. |
| Item Weight | 4.18 pounds |
| Product Dimensions | 9.84 x 10.24 x 3.54 inches |
| Item Dimensions LxWxH | 9.84 x 10.24 x 3.54 inches |
| Color | i7-6L-64G 1TB |
| Processor Brand | Intel |
| Number of Processors | 10 |
| Computer Memory Type | SODIMM |
| Hard Drive Interface | eSATA |
| Power Source | DC |
| ASIN | B0CM3KL9L7 |
| Date First Available | October 30, 2023 |
| CPU Model | Celeron |
| CPU Speed | 5 GHz |
| Graphics Card Description | Integrated |
| Memory Storage Capacity | 64 GB |
| Memory Slots Available | 2 |
| Specific Uses For Product | light office use, software routing, virtualization, edge computing, small-scale NAS, and running industry-specific software applications See more |
| Personal computer design type | Mini PC |
