Shuttle XPC Cube SH570R6-PLUS Mini Barebone PC Intel H570 Chipset Supports 125W 11th/10th Gen Rocket Lake/Comet Lake CPU No RAM No HDD/SSD No CPU No OS 500W 80 Plus Gold Flex PSU
Be the first to rate this
Highlights
- Supports Intel 11th/10th Generation Rocket Lake/Comet Lake i3/i5/i7/i9 Pentium/Celeron 125W processors with UHD Graphics No RAM no HDD/SSD No OS Compatible with Windows 11/10 (64-bit) and Linux (64-bit)
- Does not support the Unlock-function of Intel K-Series processors. Intel processors without integrated graphics can be identified by their model name ending on "F". When using this CPU, a graphics card is required.
- 4x 288 pin dual Channel DDR4 DIMM Slots 32GB per DIMM (Max 128GB). The maximum DDR4 clock frequency depends on the processor type used. Gen. 11 "Rocket Lake" supports DDR4-3200. Gen. 10 "Comet Lake" Core i7/i9 supports DDR4-2933. Other "Comet Lake" support DDR4-2666. Dual Intel Gigabit LAN 1x HDMI 2x Display Port Triple video output that support four of 4K UHD displays at 2160P/60 Hz frame rate. Support RAID 0 1 5 10. 10x USB. 1 x 5 25" ODD bay 2x 3 5" HDD bay. M.2 2280 slot.
- 1x PCI-Express x16 v4 1x PCI-Express x4 v3 slot (open-ended). Supports dual-slot (double-width) graphics cards (occupies the second PCI-Express slot). The maximum size acceptable for display cards is 273 x 98 x 38 mm. Graphics power connector is 6 pins.
- Manufacturer 3-Year Warranty and free lifetime technical support
Description
The Shuttle XPC Barebone SH570R6 Plus shows how discreet a modern PC can look and at the same time how powerful it can be. Its black-brushed aluminium case has barely a volume of 14 litres, but packs everything you need for a high-performance workstation for example. This includes the power of 10th/11th gen. Intel Core processors ("Comet Lake-S" and "Rocket Lake-S"), a dual-slot graphics card, fast M.2 NVMe SSD drives, two 3.5'' hard drives in RAID and up to 128 GB of DDR4 memory, plus an optical drive. Even without a dedicated graphics card, up to three UHD displays are supported optionally
Photos
Product specs
| Specification | Details |
|---|---|
| Screen Resolution | 3840 x 2160 |
| Max Screen Resolution | 3840 x 2160 pixels |
| Processor | none |
| RAM | 128 GB DDR4 |
| Memory Speed | 3.2E+3 MHz |
| Hard Drive | SSD |
| Graphics Coprocessor | Integrated Graphics |
| Chipset Brand | Intel |
| Card Description | Integrated |
| Wireless Type | 802.11ac |
| Number of USB 2.0 Ports | 4 |
| Number of USB 3.0 Ports | 6 |
| Brand | Shuttle |
| Series | SH570R6-PLUS |
| Item model number | SH570R6-PLUS |
| Operating System | Windows 10 Pro |
| Item Weight | 10.53 pounds |
| Package Dimensions | 19 x 13 x 11 inches |
| Color | Black |
| Processor Brand | Intel |
| Number of Processors | 2 |
| Computer Memory Type | DDR4 SDRAM |
| Hard Drive Interface | Solid State |
| ASIN | B0BM5DFGPW |
| Date First Available | October 1, 2022 |
| CPU Model | None |
| Graphics Card Description | Integrated |
| Memory Storage Capacity | 128 GB |
| Specific Uses For Product | Video Editing, Everyday Use, Gaming |
| Personal computer design type | Mini PC |
| Model Name | SH570R6-PLUS |
| Included Components | Water Cooling |
